L series

Lemokey L3 QMK/VIA Wireless Custom Mechanical Keyboard ISO Layout Collection

Lemokey L3 QMK/VIA Wireless Custom Mechanical Keyboard ISO Layout Collection

Regular price $214.00
Regular price $214.00 Sale price $214.00
Sale Available soon
Shipping calculated at checkout.
Type
Layout Version
Switches
The Fully Assembled version includes:
  • The keyboard PCB, the case, and the PC plate.
  • Keycaps (included Mac & Windows keycaps).
  • Switches.

The Barebone version does not include the keycaps and switches.
No discount codes can be used for L3 ISO.

View full details

LEMOKEY L3
ISO Layout
Versions

Meet the Lemokey L3 ISO, a 2.4 GHz full metal QMK custom mechanical keyboard built for peak performance. Dominate the game in style with the 2.4 GHz wireless connection in the L3’s solid metal body. The open-sourced QMK software brings endless possibilities for you to customize your favorite keys and macros with ease.

Lemokey L3 QMK/VIA Wireless Custom Mechanical Keyboard ISO Layout CollectionLemokey L3 QMK/VIA Wireless Custom Mechanical Keyboard ISO Layout Collection

As a brand of Keychron, the Lemokey L3 ISO can be assembled easily so you can fine-tune each component the way you want, together with a flexible double-gasket design, hot-swappable PCB, and Bluetooth connectivity for multitasking, the L3 is ready to bring a whole new gaming experience in no time.

Features-of-Lemokey-L3-ISO.jpg__PID:790365e0-7bbd-49c3-9c1e-a5510f14f8da
Customize Your L3 ISO

Choose the keycaps, switches, and more accessories for your L3.

L3 ISO Layout Versions

L3 ISO includes the UK, German, Swiss, and Nordic layouts, each equipped with extra keycaps suitable for Windows and Mac devices.

🇩🇪 German DE-ISO Layout

Lemokey-L3-German-DE-ISO-Layout.png__PID:f58ee1a0-628d-4946-a24e-18e9661bfb4d

🇬🇧 UK-ISO Layout

Lemokey-L3-UK-ISO-Layout.png__PID:628d7946-a24e-48e9-a61b-fb4dc8c64712

🇩🇰 🇫🇮 🇳🇴 🇸🇪 Nordic-ISO Layout

Lemokey-L3-Nordic-ISO-Layout.png__PID:e1a0628d-7946-424e-98e9-661bfb4dc8c6

🇨🇭Swiss-ISO Layout

Lemokey-L3-Swiss-ISO-Layout.png__PID:7946a24e-18e9-461b-bb4d-c8c6471211d0

Play Wirelessly

2.4 GHZ WITH 1000 HZ POLLING RATE

Get ready for a brand new gaming experience with the L3’s 2.4 GHz wireless connection with a 1000 Hz polling rate. You can also connect the L3 with up to 3 devices through its stable  Bluetooth 5.1 for seamless multitasking across your computer, phone, and tablet. Switch among them swiftly.

Lemokey L3 QMK/VIA Wireless Custom Mechanical Keyboard ISO Layout Collection

Full Metal

DURABLE AND TOUGH

The L3 is not just a tool, but a piece of art on your desk. The L3 is created with a 6063 aluminum CNC machined body, polished, anodized and sandblasted finish, and twenty-four manufacturing processes.

Lemokey L3 QMK/VIA Wireless Custom Mechanical Keyboard ISO Layout Collection
Lemokey L3 QMK/VIA Wireless Custom Mechanical Keyboard ISO Layout Collection
Section
Drop element here

Modular Design

CUSTOMIZE WITH EASE

Every detail matter to make your favorite keyboard, that’s why every component on the L3 can be assembled, customize and adjust easily to create your ultimate typing experience.

Structure of Lemokey L3 ISO
Structure of Lemokey L3
Section
Drop element here

Double-Gasket

DAMPENED SOUND AND ELASTIC

Experience the next level of key sounds and comfort with the Keychron signature double-gasket mount design. This design allows the keyboard to maintain the flexibility of the gasket structure and improves the overall typing sound.

Double-Gasket-Design

Double-Shot PBT

OSA PROFILE NON-BACKLIT KEYCAPS

To further leverage your typing experience, the L3 ISO version comes with our unique OSA profile (OEM profile with spherical angle) and non-backlit PBT keycaps that aim to provide a more comfortable fingertip feel, excellent oil resistance, and prevent the legends from fading out.

OSA Profile ABS Keycap
OSA-Profile-Keycap-2.jpg__PID:a3dad90a-24c9-4040-ad91-b53241365c25

Programmable

KNOB & MACRO COLUMN

Upgrade your gaming experience with the additional macro keys and aluminum rotary encoder. It allows you easily customize the knob to your desired key or macro commands like zooming in/out, adjusting screen brightness, or volume, etc

Knob & Macro Column of Lemokey L3 ISO

QMK/VIA

REMAP ANY KEY AND ANY MACRO

The open-sourced QMK/VIA software is offering endless possibilities for anyone to remap any key and create any macro commands, shortcuts, or key combinations with ease right in a browser. You can also store your favorite setting with the L3’s onboard memory.

Simply connect the L3 to your device with a cable, open the VIA software, import the JSON file, drag and drop your favorite keys or macro commands to remap any key you want on any system (macOS, Windows, or Linux). It’s never been so intuitive to personalize your very own keymap.

Check out the video above demonstrating how to remap the M1 key to a Sleep key with the VIA software to create a shortcut to put your Windows to sleep (Win + L).

A brand new powerful ultra-low-power Arm chip (MCU) that is armed with 256K Flash to provide more flexibility for developers, and makes latency non-existent for the competitive gamer.

Get the L3 keymap working on VIA

Since the VIA code for the L3 is still awaiting approval from Github, it is not yet automatically recognized. Please download the appropriate keymap JSON file (ANSI or ISO) below, open VIA, turn on "Show Design tab" on "Settings" tab, and drag the JSON file into the “Design” tab on VIA to get the L3 keymap working on VIA.

ZMK
pf-c4bbc56a--25358678__PID:1b890f85-1d4f-42c1-97b6-befb3965b5ed
Keychron Launcher

REMAP ANY KEY AND ANY MACRO

The open-source QMK firmware means endless possibilities for key remapping, macros, shortcuts, and more. Now you can easily customize each key with the Lemokey Launcher web app.

L3 ANSI Launcher.png__PID:1365cfda-c294-408c-8a7a-cd5785dad5e8
Click here to use Lemokey Launcher

* Please use the latest version of Chrome / Opera / Edge browser to open the Launcher and connect the keyboard to your device via wired mode.

Hot-swppable feature of Lemokey L3 ISO

Hot-Swappable

CUSTOMIZE YOUR SWITCH ANYTIME

Every detail matters for a personalized typing experience, that’s why we give you the power. You can hot-swap every switch on the L3 with almost all of the 3pin and 5pin MX style mechanical switches on the market (including Cherry, Gateron, Kailh, Panda, etc.) without soldering required. You can customize your own typing experience in seconds.

Section
Drop element here

For More Keycap Profile

SOUTH-FACING RGB

The south-facing RGB is designed to illuminate backlight to the typist when the non-shine-through PBT keycaps are installed. With 22 types of RGB backlight settings (Watch the video above for all backlight settings), you can further fine-tune the RGB hue, saturation, brightness, effect speed, and different modes, or even remap these keys with Launcher web app.

Gateron Jupiter Switch

PRE-LUBE AND RELIABLE

Our exclusive Gateron Jupiter mechanical switch (for the Fully Assembled version only) comes with a 5-pin design, its pre-lubed with a reliable Gateron quality standard with up to 80 million keystrokes lifespan. While their unique LED diffuser design offers high RGB backlight transmittance and softer backlight effect.

Gateron Jupiter Mechanical Switch

Screw-In Stabilizers

SMOOTH AND STABLE

The built-in PCB-mounted screw-in stabilizers create a smooth typing experience with less wobbliness on the big keys such as space bar, shift, enter, and delete. You can even customize your favorite 3rd parties stabilizers on your own.

PCB screw-in stabilizers of Lemokey L3
PCB screw-in stabilizers of Lemokey L3

What's in the box?

L3-ISO-Fully-Assembled-Knob-Version.jpg__PID:8cca7acd-5785-4ad5-a86e-60e14c281790
L3-ISO-Barebone-Version.jpg__PID:7acd5785-dad5-486e-a0e1-4c281790040b

What's in the box?

Package list of Keychron Q5 Pro fully assembled knob version
Package list of Keychron Q5 Pro barebone knob version

Specs

Dimension401 x 137 mm (15.78 x 5.39 inches)
Number of Keys91 (Unique tenkeyless layout)
Layout ISO (EU)
Back Height without keycaps29.84 mm (1.17 inches)
Front Height19.8 mm (without keycaps)
Back Height29.84 mm (without keycaps)
WeightAbout 1976 g (Fully Assembled version)
Frame MaterialFull CNC machined aluminum
Plate MaterialPC
KeycapDouble-shot PBT keycaps, not shine-through, OSA Profile (OEM height, SA shape)
SwitchGateron Jupiter (Fully Assembled version)
StabilizerScrew-in PCB stabilizer
Switch FaceSouth-facing RGB
Backlight22 types of RGB backlight options plus endless possibilities
Hot-swappableYes. Compatible with most of the 3 pin & 5 pin MX mechanical switches such as Gateron, Cherry MX and Kailh, etc.
MCUARM Cortex-M4 32-bit STM32F402 (256KB Flash)
Cable Length1.8 m
Polling Rate1000 Hz (2.4 GHz and wired) / 90 Hz (Bluetooth mode)
N-Key Rollover (NKRO)Yes for both wireless and wired modes
Operating Environment-10 to 50℃
Battery4000 mAh Rechargeable li-polymer battery
BT Working Time (Backlit off)Up to 200 hours (Lab test result may vary by actual use)
BT Working Time (RGB)Up to 100 hours (Lowest brightness)
Charging TimeAround 5 hours
Charging PortUSB type-C
Bluetooth Version5.1
Compatible SystemWindows/macOS/Linux
Connectivity2.4 GHz/Bluetooth / Type-C wired
Bluetooth Device NameLemokey L3
Bluetooth Operating DistanceWithin 10 meters (Open space)
